GF14
Call for Pricing
Price
Make:
Load Trail
Model:
GF14
Category:
Car and Equipment Hauler, Gooseneck, Load Trail, New
| Axles: | 2-7,000 Lb Cambered Dexter Spring 2 Elec. NEV-R-ADJUST Brakes |
| Couplers: | 2 5/16″ Adjustable Coupler Round (25,000 lb) |
| Crossmembers | 3″ Channel 16″ OC (3.5 lbs/ft) |
| D-Rings: | |
| EWR Class | CARHAULER |
| Fenders: | Weld On Diamond Plate |
| Finish (prep): | Mechanical and/or Chemical Pretreatment for Maximum Paint Adhesion |
| Finishing Coat/Primer | Sherwin-Williams Powdura OneCure Primer w/Polyester TGIC Gloss Powder Topcoat |
| Flooring: | Treated Wood |
| Frame: | 8″ Channel (11.5 lbs/ft) |
| GAWR: | 7,000 lb ( ea axle) |
| GVWR: | 14,000 lb |
| Jack: | 2-10K Drop Leg Spring Return |
| Lights: | D.O.T. Stop, Tail, Turn and Clearance LED |
| Neck | 12″ I-Beam (14 lbs/ft) |
| Product Line | Car-Haulers & Bob Cats |
| Product Series: | GF14 |
| Ramps: | 5′ Slide-In Ramps |
| Safety Chains: | 18,800 Lb 5/16 x 36 G#70 |
| Side Rails: | Weld-On |
| Suspension: | Multi-Leaf Slipper Spring |
| Tires: | 235/80 R16 LRE |
| Tool Box: | Front Tool box |
| Top Rail: | 3″ Pipe |
| Tougue & Neck: | 12″ I-Beam (14 lbs/ft) |
| Up Rights: | 2-1/2″ x 2-1/2″ x 3/16″ Angle Iron |
| Wheels: | 16″ 8-Hole |
| Wire Harness: | 16 Ga. 5-Way Double Insulated Harness w/7-way plug |
